SFP 1G Multimode

The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 550m transmission distance with MMF. The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Category:

Description

Features

1. Dual data-rate of 1.25Gbps/1.063Gbps operation
2. Data-rate of 1.25Gbps operation
3. 850nm VCSEL laser and PIN photodetector
4. Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
5. Digital Diagnostic Monitoring:
6. Internal Calibration or External Calibration
7. 500m transmission with 50/125µm MMF
8. 300m transmission with 62.5/125µm MMF
9. Compatible with RoHS
10. +3.3V single power supply
11. Operating case temperature: Standard: 0 to +70°C, Extended: -20 to +85°C
